TTP-268M/ TTP-366M
Bar Code Printer Service Manual
2. ELECTRONICS
2.1 Summary of Board Connectors
Main board
Connector
Description
1
Centronics port connector
2
USB connector
3
RS-232C connector
4
LCD panel connector
5
Multi-interface board connector/ GPIO interface board
6
Micro processor
7
RFID module connector
1
2
3
4
5
6
7
9
13
8
11
12
14
17
18
19
10
15
16
20
