22
NOTE: 5k, 6.25k, 8.33K,10k, 12.5k, 20k, 25k, 30k and 50k total nine step size available for
this radio.
Transmitting
Press key or press MIC's key to monitor for a while to confirm the channel
desired is not busy. Release or press Mic's key to return standby status,Then press
and hold [PTT] key to speak into microphone.
P2
P2
Receiving
When the channel you are operating is called, the screen
shows and field intensity, in this way, you can hear the
calling from transmitting party.
NOTE: If the transceiver has set at higher squelch level, it may fail to hear the calling.
When the channel you are operating is called,the screen shows BUSY and field intensity,
you can't hear the calling from transmitting party,it means current channel receives a
matching carrier but unmatching signaling(Refer to CTCSS/DCS encode and decode or
Optional Signaling setup).
Please hold the microphone approximately 2.5-5.0cm from your lips, and then speak into
the microphone in your normal speaking voice to get best timbre.
NOTE:Press and hold [PTT] key, LED lights RED and power intensity showed in screen
indicates it is transmitting, release to receive.
Transmitting Tone-pulse
Press and hold [PTT] key, then press Microphone transmit current selected
tone-pulse signal.
Transmitting Optional Signaling
Press and hold [PTT] key, then press Microphone key or press key in front
panel or press Mic's key to transmit pre-stored and selected DTMF/2Tone/5Tone
optional signaling.
Channel Edit
1. Press key to enter CTCSS/DCS signaling setup, turn
selector knob to select the desired signaling.
2. Press key, LCD appears , Micon and current
channel number, Micon flashing means current channel is empty.
3. Turn selector knob to select the desired channel number to store.
4. Press key, , Micon and channel number disappears and emit a prompt voice,
thus the channel storage succeed.
23
