X or Y S or T
Distances between gears
With the aim of minimising noise and friction, the cranks-
haft, primary shaft and balance shaft gears exist as joint
assemblies.
PRIMARY SHAFT- GEAR SET
X CLASS
Y CLASS
CRANKSHAFT GEAR
REFERENCE
8714605001
8714605002
REFERENCE
8714475001
8714475002
N.B.: The crankcases available as spare parts are always of the X kind.
X CLASS
Y CLASS
MIN
86.04
86.00
86.00
85.96
MAX
BALANCE GEAR
N.B.: the distances between the primary shaft and the crankshaft are the following.
16
SETS IDENTIFICATION
