C YLINDER HEAD AND CYLINDER PARTS
Piston-cylinder assy.
1st cat. piston assy.
Cylinder – cylinder head gasket
Cylinder - crankshaft gasket
First piston ring
Scraper ring
Piston gudgeon pin
Piston gudgeon pin circlip
Chain tensioner
Gasket
M6x16 bolt
1
3
4
5
6
7
8
9
10
11
12
89
ASSEMBLING THE ENGINE
AND ADJUSTMENTS
WORKSHOP MANUAL
