UNI-T UT20B User Manual

Accuracy Specifications (3)
E. Diodes Test
D. Battery Test
Range
1.5V
9V
Internal Resistance
30Ω
1.8kΩ
Overload Protection
Maximum current: 50mA.
Maximum current: 5mA.
Remark:
l Displays battery’s voltage value between the cathode and anode.
Range Resolution
1mV
Remarks
l Open circuit voltage approximate 3V.
l Displays approximate forward voltage drop: 0.5V~0.8V.
26
Model UT20B: OPERATING MANUAL

UNI-T UT20B Specifications

General

Diode test	Yes
Product type	Digital multimeter
DC current range	0.2 - 2 A
DC voltage range	0.2 - 300 V
Statistic function	Maximum
Basic accuracy (DC current)	±(2.5%+10)
Basic accuracy (DC voltage)	±(1.5%+2)
Basic accuracy (resistance)	±(2.5%+5)
Dimensions (WxDxH)	52 x 26 x 95 mm
Battery voltage	12 V

Weight and Dimensions

Weight	125 g
