UNI-T UTG2122B User Manual

124 UTG2000B Series
Trigger input
Input level
TTL compatible
Slope
Rising or falling, optional
Pulse width
> 100 ns
Input impedance
> 10kΩ,DC coupling
Response time
Frequency sweep：< 500μs,typical value
Pulse train
：<
500ns,typical value
Trigger output
Level
TTL compatible
Pulse width
> 400ns,typical value
Output impedance
50Ω,typical value
Maximum frequency
1 MHz
Frequency meter
Input level
TTL compatible
Range of input
frequency
100mHz~200MHz
Accuracy
±51ppm
Frequency resolution
6 digit/s
coupled mode
DC
general technical specifications
Display
LCD
4.3 inches TFT
resolution
480×272
Power supply
Power supply
100~240 VAC,45~440Hz,CAT II
Power consumption
Less than 50W
Fuse
2A,Class T,250V
Environment
Temperature range
operating：10˚C~+40˚C
Non-operating：-20˚C~+60˚C
Cooling method
Forced fan cooling
Humidity range
Below +35˚C：≤90% relative humidity
+35˚C ~+40˚C ≤60%relative humidity
Altitude
Operating below 2,000m˚C
Non-operating below 15,000m
Mechanical specification
Dimensions
305mm×230mm×93mm
Net weight
3.10kg
Rough weight
4.10kg
