SLICER BASE REMOVAL
1. Warning: Disconnect the electrical power supply cord.
2. Place the operating mode switch in the manual position.
3. Remove the six pan head screws (Figure 18 [5]) and remove the bottom cover (Figure 18 [16]).
4. Remove the four rubber feet and remove the four socket head cap screws (Figure 18 [7]) and
carefully remove the slicer base while guiding the belt out of the jaw assembly.
CARRIAGE DRIVE BELT REPLACEMENT
1. Remove the slicer base assembly per the above procedures.
2. Loosen the four socket head cap screws (Figure 20 [7]) in the bearing block (Figure 20 [22]).
3. Loosen the jam nut (Figure 20 [23]) and loosen the belt tensioning screw (Figure 20 [24]).
4. Remove the carriage drive belt (Figure 20 [13]).
CARRIAGE DRIVE MOTOR BELT REPLACEMENT
1. Remove the slicer base assembly per the above procedures.
2. Loosen the two socket head cap screws (Figure 20 [7]) in the motor mounting angle
(Figure 20 [2]).
3. Loosen the jam nut (Figure 20 [23]) and loosen the belt tensioning screw (Figure 20 [24]) in the
motor mount (Figure 20 [2]).
4. Remove the carriage drive motor belt (Figure 20 [4]).
CARRIAGE DRIVE MOTOR REPLACEMENT
1. Remove the slicer base assembly and the carriage drive motor belt per the above procedures.
2. Disconnect the motor wires from the control box (Figure 18 [36]).
3. Remove the two socket head cap screw (Figure 20 [7]) in the motor mounting angle
(Figure 20 [2]) and remove the motor and motor mounting angle.
4. Remove the four socket head cap screws (Figure 20 [28]) and remove the motor.
