Univex 1000S User Manual

KNIFE ASSEMBLY
FIGURE 10
ITEM N
o. PART No. DESCRIPTION QTY.
1. F4020084 Body, Slicer GL12 (manual) 1
F Body, Slicer (automatic) 1
2. F303040 Foot, Rubber 4
3. F406BA03 Spacer, Foot 2
4. F7001758 Screw, Socket Head Set M8-1.25 x 35 2
5. F4101082 Screw, Deflector 1
6. F700264F Washer, Bellville 1
7. F405BC07 Deflector 1
8. F7004006 Nut, M6 2
9. F7003806 Washer, M6 2
10. F7001749 Screw, Socket Head Set M6-1.0 x 30 3
11. F4121185 Foot, Stand-off 2
12. F4101183 Stand-off, Lower 1
13. F7003335 Screw, Socket Head Set M6-1.0 x 14 1
14. F3024110 Knife 1
15. F7000634 Screw, Slotted Flat Head M5-0.8 x 12 4
16. F7002426 Screw, Slotted Flat Head M4-.07 x 10 2
17. F4020172 Cover, Knife 1
18. F4090300 Handle, Knife Cover 1
19. F4101064 Insert, Knife Cover 1
20. F202V006 Knife Drive Assembly (figure 8) 1
21. F4100645 Stand-off, Side 1
22. F3040127 Plug 1
23. F7003336 Screw, Socket Head Cap M6-1.0 x 18 1
24. F4020462 Guard, Protective 1
25. F4090004 Boot, Rubber 1
26. F4100692 Sleeve 1
27. F7003546 Screw, Socket Head Set M6-1.0 x 12 1
28. F4020400 Support, Guard 1
29. F3030525 O-Ring 1
30. F4100935 Post 1
31. F4100682 Shaft, Blade Cover 1
32. F4100818 Collar, Switch 1
33. F4100056 Bushing 1
34. F4100052 Shaft, Switch 1
35. F4090304 Knob, Knife Guard (aluminum) 1
F4101231AC Knob, Knife Guard (plastic)
36. F3040212 Switch 1
Page 19
