V2 GOLD400D Series User Manual

ENGLISH
35
QUICK CONFIGURATION
This paragraph concerns a quick procedure to set the control
unit and set it at work immediately.
We recommend following these instructions, in order to check
quickly the correct operation of control unit, motor and
accessories, and then changing the configuration in case of
any non-satisfactory parameter.
Please refer to the paragraph “CONTROL UNIT
C
ONFIGURATION” for the item position inside the menu, as
well as for the available options for each item.
1. Call up the default configuration: see paragraph “LOADING
O
F DEFAULT PARAMETERS”
2. Set items StoP, Fot1, Fot2, CoS1, CoS2 e FC.En according
to the safety devices installed on the gate.
3. Start the self-learning cycle (item APPr).
This last operation will close the configuration menu and store
set up parameters.
Self-learning procedure:
• In case the end of stroke or the obstacle sensor has been
enabled, the gate will be activated in closing direction until
the stop end or the closing end of stroke is reached.
• In case NEITHER the ends of stroke OR the obstacle
sensor have been enabled, be sure that the gate is
completely closed when the procedure is started up.
• The gate will be activated in opening direction until the
stop end or the opening end of stroke is reached.
• In case the sensors have not been enabled, or if you realize
that they do not signal the position to the control unit, you
must send a START command when the gate reaches its
max. opening position.
• The gate will be activated in closing direction until the stop
end or the closing end of stroke is reached.
• In case the sensors have not been enabled, or if you realize
that they do not signal the position to the control unit, you
must send a START command must be sent when the gate
reaches its fully closed position.
CONTROL UNIT
CONFIGURATION
In the following page there is the step-by-step procedure to
set all operation parameters of Pd8 control unit.
You can either follow all procedure steps and perform a
complete control unit configuration or select and adjust
interesting items only. As for both cases, you will have to
perform the right exit procedure through item FinE, in order
to activate your new configuration.
Pd8 control unit provides for a self-learning procedure of
working times; therefore, we recommend that you set up a
standard configuration first (see previous paragraph), then you
carry out the self-learning and finally you change any
unsatisfactory items.
