V2 JEDI-L User Manual

ENGLISH
11
TECHNICAL SPECIFICATIONSINDEX
DECLARATION OF CONFORMITY . . . . . . . . . . . . . . . . . . . . . . .11
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . .11
IMPORTANT REMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
PRELIMINARY CHECKINGS . . . . . . . . . . . . . . . . . . . . . . . . . . .13
INSTALLATION LAYOUT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
I
NSTALLATION OF GUIDE SECTION BAR . . . . . . . . . . . . . . . . . .14
INSTALLATION OF MOTOR ON SECTION BAR . . . . . . . . . . . . . .15
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
RELEASE OF THE AUTOMATION . . . . . . . . . . . . . . . . . . . . . . .16
ELECTRICAL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . .16
SET-UP OF OPERATIONAL PARAMETERS . . . . . . . . . . . . . . . . . .17
MEMORISING REMOTE CONTROL UNITS . . . . . . . . . . . . . . . . .20
DELETING REMOTE CONTROL UNITS . . . . . . . . . . . . . . . . . . . .20
EC DECLARATION OF INCORPORATION FOR
PARTLY COMPLETED MACHINERY
(Directive 2006/42/EC, Annex II-B)
The manufacturer V2 S.p.A., headquarters in
Corso Principi di Piemonte 65, 12035, Racconigi (CN), Italy
Under its sole responsibility hereby declares that:
the partly completed machinery model(s):
JEDI-L
Identification number and year of manufacturing: typed on
nameplate
Description: electromechanical actuator for garage doors
- is intended to be installed on garage doors to create a machine
according to the provisions of the Directive 2006/42/EC.
The machinery must not be put into service until the final
machinery into which it has to be incorporated has been declared
in conformity with the provisions of the Directive 2006/42/EC
(annex II-A).
- is compliant with the applicable essential safety requirements
of the following Directives:
Machinery Directive 2006/42/EC (annex I, chapter 1)
Low Voltage Directive 2006/95/EC.
Electromagnetic Compatibility Directive 2004/108/EC.
Radio Directive 99/05/EC
The relevant technical documentation is available at the national
authorities’ request after justifiable request to:
V2 S.p.A., Corso Principi di Piemonte 65,
12035, Racconigi (CN), Italy
The person empowered to draw up the declaration and to provide
the technical documentation:
Cosimo De Falco
Legal representative of V2 S.p.A.
Racconigi, 11th January 2010
JEDI-L
Power supply 230Vac - 50Hz
Absorbed power 160W
Max accessories load 24V 12W
Protection fuses SOURCE = 2,5A
D
oor area
< 1
5m
2
Average speed 110mm/s
Peak force 1000N
Nominal force 850N
Working temperature -20 ÷ +40 °C
Rated Operating Time > 4 min.
Protection degree IP20
Weight 12Kg
