Legend Traditional Logs 739LSK
Material required
• Traditional Log Set, which contains:
• 6 logs
• Gloves, if desired, not included
Installation
Carefully unpack the kit. Some logs have pegs to help
their placement. Install the logs as shown below. Please
note that the position of the logs is critical to ensure
proper performance of the appliance.
1. Place the rear log on the sheet metal support cen-
tering it side to side in the fi rebox. Pull it forward un-
til the notch in the underside of the log sits against
front edge of the sheet metal support.
2. Place the top left log on the pin of the rear log. The
bottom of the log rests against the left of the pilot
shield and slightly above.
Pilot area
Rear log
LH top log
LH front log
Loose coals
LH front log
RH center
log
RH top log
WARNING
Choking Hazard! Ensure that the fireplace
area is clear of ceramic coal pieces as
these could be ingested by small children.
Vacuum area after installation.
IMPORTANT
Approved for use only with the ceramic coal and
logs provided for your Valor fireplace. The use
of any other products may void your fireplace
warranty.
