Valor G3 User Manual

38
Appendix C—Spare Parts
Description
Part
Number
1 Exhaust Slide Assembly 4000127
1a 2.5-4.5” hose clamp 4000768
2Port Cover 4001820AH
3 Fuel Bed Support 4006177
3a Support Bracket - Log 4009301
4 Side Bricks Anchors (2) 4001283
5 Top Mounting Bracket 4000136AZ
6 Side Mounting Brackets (2) 4000135AZ
7 Window Assembly 4001378
7a Hot glass warning plate 4003093
8
Burner Assembly (natural gas) 4007450
Burner Assembly (propane gas) 4007451
9
Burner Rail (natural gas) 4001665
Burner Rail (propane gas) 4001666
10
Injector Elbow (natural gas) 9730012
Injector Elbow (propane gas) 9730007
11 Air Shutter Cover (natural gas) 4002346
11a Air Shutter Slider (natural gas) 4002345
12 Flashback Shield (propane gas) 3000371
12a Air Shutter Slider (propane gas) 320B293
13 Burner Baffl e 4001784
14 Burner Mounts (2) 4001678
15 Pilot Shield 4000144
16
Pilot Assembly (natural gas) 4007220S
Pilot Assembly (propane gas) 4007221S
17 Pilot Bracket 720A542
18
Pilot Injector #35 (natural gas) 4002511
Pilot Injector #27 (propane gas) 720A195
19 Hooked Olive for Pilot Injector 720A196
20 Olive Nut for Pilot Pipe 420K385
21 Electrode 4001856
22 Electrode Retaining Nut 4001855
23 Thermocouple 4000061
24 Pilot Mount 4000138
25
Pipe—Valve to Main Burner (incl. olive
& nuts)
4000065
26 Burner Tray 4001677
27 Burner Plate Access Panel 4001681
28 Olive Nut for Pilot Pipe 220K913
29 Pipe—Valve to Pilot 4001838
30 Valve Mounting Bracket 4000141
31 Thermocurrent Interruptor 4001037
Description
Part
Number
32
GV60 Valve Assembly
(natural gas)
4007440X
GV60 Valve Assembly
(propane gas)
4007441X
33 Cable interrupter-receiver (yellow) 4002096
34 Ignition Cable 500 mm 4001039
35 Ignition Cable Sleeve 4002244
36 Receiver PLUS 4001911
37 Wiring Harness 4001187
38 Vent Safety Switch Assembly 4007429
39 Handset PLUS 4001910
40 Handset Wall Holder 9000008
41 Auxiliary battery holder 4006553
42 Battery holder cable 1500 mm 4006552
43 GV60 Valve Repair Kit, not included 4004544
44 Liner Set Complete
Fluted Black 739FBL
Valor Red Brick 739VRL
Refl ective Glass 739RGL
45 Rear Panel
Fluted Black 4001814
Valor Red Brick 4001811
Refl ective Glass 4005017
46 Left Panel
Fluted Black 4001812
Valor Red Brick 4001809
Refl ective Glass 4005015
46a Filler Panel 4005018
47 Right Panel
Fluted Black 4001813
Valor Red Brick 4001810
Refl ective Glass 4005016
47a Side Spacers (4) 4004711AH
48 Rock Set Complete 739RSK
49 Rock No. 1 4001821
50 Rock No. 2 4001822
51 Rock No. 3 4001823
52 Rock No. 4 4001824
53 Rock No. 5 4001825
54 Rock No. 6 4001826
55 Rock Base 4001792
56 LH Twig 4001827
