TCI-W11, TCI-W22 Universal Controller
INPUT CONFIGURATION
Doc: 70-00-0158C, V2.0-20220523 © Vector Controls GmbH, Switzerland Page 11-22
Subject to alteration
Control configuration (Password 241)
Input configuration
Internal inputs 1T temperature and 1H humidity (with added AES3-HT-A2, -A3 or -A5 element)
Parameter
Description
Range
Default
1T 00
1H 00
Enable internal sensor
OFF/ON
ON
1T 01
1H 01
Display minimum value
-50205
0
1T 02
1H 02
Display maximum value
-50205
100
1T 03
1H 03
Sensor sampling rate (control speed decrease as rate increases)
0100
10
1T 04
1H 04
Sensor calibration
per input
0
1T 05
1H 05
Alarm 1 (1T), Alarm 3 (1H) low limit
OFF/ON
OFF
1T 06
1H 06
Alarm 1 (1T), Alarm 3 (1H) low limit values
-40215°C
5°C/5%
1T 07
1H 07
Alarm 2 (1T), Alarm 4 (1H) high limit
OFF/ON
OFF
1T 08
1H 08
Alarm 2 (1T), Alarm 4 (1H) high limit values
-40215°C
50°C / 95%
1T 09
1H 09
Hysteresis Alarm 1, 2 (1T), Alarm 3, 4 (1H)
0100°
5°C/5%
1T 10
1H 10
Calculate a range of inputs (0= not active):
1= average, 2= minimum, 3= maximum, 4= differential
03
0
Universal inputs 1U =UI1, 2U = UI2 (TCI-W22 only)
1U 00
Signal type (0= not active):
1= 0-10V or 0-20mA, 2= 2-10V or 4-20mA, 3= passive temperature
03
1
1U 01
Display minimum value
-50205
0
1U 02
Display maximum value
-50205
100
1U 03
Analog input display range: 0= x 0.1, 1= x 1, 2= x 10, 3 = x 100
03
1
1U 04
Analog input unit of measure: 0= no unit, 1= %, 2= °C /°F, 3= Pa
03
2
1U 05
Sensor sampling rate (control speed decrease as rate increases)
0100
10
1U 06
Sensor calibration
Per input
0
1U 07
Alarm 5 (1U), Alarm 7 (2U) low limit
OFF/ON
OFF
1U 08
Alarm 5 (1U), Alarm 7 (2U) low limit value
-40215°C
5°C (41°F)
1U 09
Alarm 6 (1U), Alarm 8 (2U) high limit
OFF/ON
OFF
1U 10
Alarm 6 (1U), Alarm 8 (2U) high limit value
-40215°C
50°C (122°F)
1U 11
Hysteresis alarm 5 and 6 (1U), alarm 7 and 8 (2U)
0100°
5°C (10°F)
1U 12
Calculate a range of inputs (0=not active):
1= average, 2= minimum, 3= maximum, 4= differential
04
0
Set jumpers on the back of the controller: 010VDC (default), 020mA, or RT/DI (passive temperature or binary)
Further define analog inputs with U00
Match sensor range to input display. With a differential pressure transmitter having 0200 Pa measuring range set
UO1 display minimum to 0 and U02 display maximum to 200. The allowable range value of -50205 may be adjusted
with multipliers inU03. The largest displayable values are -9909999. Limiting range increases resolution. Applies to
analog as well as passive temperature inputs.
For binary input (open/close contact) set the jumper to RT/DI and parameter U00 to an analog input. An open
contact reads as a high value (100%), a closed contact as a low value (0%).
Enable / Disable an alarm. Setting the alarm enable to OFF will prevent the alarm from being displayed on screen. It
may never the less be used to control an output by setting the appropriate output alarm flags. This way, an alarm
limit may be used as interlock.
Specify the input value that triggers an alarm. Hysteresis is the difference between alarm level input and value
required to turn the alarm off. An alarm is displayed as text if enabled (see table). Alarm text can be set to blink
continuously until acknowledged by pressing the OPTION button or only while the alarm conditions are active (see
user parameter UP15).
Calculate mathematical functions over multiple inputs for loop control or display with xU12. In order to calculate
average, minimum or maximum between several inputs, make sure all the inputs are of identical type and range and
then activate the same function on xU12 on all the selected inputs. The largest input of the group selected will carry
the calculated value. For example: When average is activated on 2U12 and 1U12 = 1, the average is carried on
UI2.UI2 may now be used as input for control loops and it will show the average value of UI1 and UI2 combined. It is
possible to use different functions on different inputs. For example: minimum of UI1 and UI3 and maximum of UI2
and UI4.
The differential function may only be calculated on subsequent inputs. Such as UI2-UI1. The function must only be
activated on the minuend (UI2 in this example). The displayed value of the minuend will change into the difference:
UI2 in UI1 = UI2 out. It is possible to have multiple differentials on one controller. It is not possible to reverse the
subtraction to UI1-UI2.
Input
1T
1H
1U
2U
Low limit
ALA1
ALA3
ALA5
ALA7
High limit
ALA2
ALA4
ALA6
ALA8
