Veeder-Root TLS-350R PLUS Troubleshooting Guide

34
ISD/PMC Diagnostic Menus
The diagnostic menus below are viewed from the TLS Console front panel. Consult manual 577013-800 for the
procedure used to selecting/changing Diagnostic Mode setup parameters via the front panel keys.
SMARTSENSOR DIAGNOSTIC
PRESS <STEP> TO CONTINUE
SYSTEM DIAGNOSTIC
PRESS <STEP> TO CONTINUE
DIAG MODE
PRESS <FUNCTION> TO CONT
s 1: VP: FP1 - 2
COMM DATA PRESS <PRINT>
Prints out comm diag - see example below
Prints out constants diag - see example below
Prints out channel diag - see example below
To select another sensor
F
F
S
T
P
To select another sensor
S
T
P
To select another sensor
S
T
P
s 1: VP: FP1 - 2
CONSTANTS PRESS <PRINT>
s 1: VP: FP1 - 2
CHANNELS PRESS <PRINT>
SS COMM DIAG
-----------------------
s 1: AFM1 FP1-2
SAMPLES READ 58
SAMPLES USED 54
PARITY ERR 0
PARTIAL READ 0
COMM ERR 0
RESTARTS 0
SS CONSTANTS DIAG
-----------------------
s 1: AFM1 FP1-2
VAPOR PRESSURE
SERIAL NUMBER 1007
PROTOCOL VERSION 0
SS CHANNEL DIAG
-----------------------
s 1: AFM1 FP1-2
YY-MM-DD HH:MM:SS
C00 B50B 3D68 00E0 0000
C04 0000 03EF 0000 0004
C08 0A3C 3D68 5693 0081
C12 80C4 80A4 0104 2579
C16 0000 0000 00A3 03D6
C20 0709 0032 04C9 880F
ISD-EVR/fig2.eps
E
F
P
S
T
Enter
Function
Print
Step
Tank/Sensor
Repeat key
presses
Key Legend
