Work steps Responsible party Page
Type OPTO2 Type OT2
Installation
1 Check the system requirements. Contractor
IT professional
11 11
2 Insert cables. Contractor
System user
— 15
3 Install the wall bracket for the Vitoconnect. Contractor
System operator
14 14
4 Fit wall mounting bracket for Vitotrol 100. Contractor
System operator
— 14
5 Connect the Vitoconnect to the heat generator. Contractor — 16
Contractor
System user
16 —
7 Connect Vitoconnect and Vitotrol 100. Contractor
System operator
— 17
8 Insert the Vitoconnect in the wall bracket. Contractor
System operator
17 17
9 Insert Vitotrol 100 into wall mounting bracket. Contractor
System operator
— 18
10 Set up the Vitoconnect mains connection. Contractor
System operator
18 18
Commissioning
11 Check the network settings. IT professional 20 20
12 Register the user. Set up the heating system. Contractor
System operator
21 21
13 Only in conjunction with an energy manage-
ment system:
Establish the connection to the energy manage-
ment system.
Contractor 21 21
Installation sequence
Overview of steps for installation and commissioning
5813605
