Removing the Stand and Mounng the Monitor
Refer to the table below for the standard dimensions for mounng kits.
NOTE:  For use only with a UL cered mounng kit/bracket. To obtain a wall
mounng kit or height adjustment base, contact ViewSonic® or your
local dealer.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw
Specicaon
Screw
Quanty
14 kg 100 x 100 mm N/A N/A M4 x 10 mm 4
NOTE:  Mounng kits are sold separately.
1. Turn o the monitor, disconnect all cables, and remove the remote control.
2. Place the monitor on a at, stable surface with the screen facing down.
3. Unscrew the captured screw in the monitor stand’s base and remove it from the
monitor stand’s neck.
Battery
1
2
4. Press and hold the quick release tab and carefully li the stand.
Battery
1
2
