24
The Engines
1.9-litre 74 kW TDI engine with
The 1.9-litre 74 kW TDI engine is based on
the 1.9-litre TDI engine developing 85 kW.
It differs from the basic engine in the following
respects:
● The software used in the engine control unit
was adapted to the lower engine power.
● The injectors have smaller
nozzle holes.
Specifications
Engine code AVB
Type In-line engine
Number of cylinders 4
Number of valves per
cylinder
2
Compression ratio 19:1
Displacement 1896 cm
3
Bore 79.5 mm
Stroke 95.5 mm
Max. power 74 kW/100 bhp
4000 rpm
Max. torque 250 Nm
@ 1900 rpm
Engine management
system
BOSCH EDC 15 P
Mixture preparation Direct injection by
pump injection
system
Fuel grades 49 CN diesel,
biodiesel
pump injection system
251_034
251_024
