46
The Electrics
Networking of CAN systems
Injection pump
(V-6 TDI)
Gearbox control
unit
Brake control unit
(ABS, ESP,...)
Airbag control
unit
Wheel angle sen-
sor (for ESP)
Radio
(Double DIN
US market)
Multifunctional
steering wheel
Fuel tank sender
(B5-W8 only)
Climatronic
Driver door con-
trol unit
Front passenger
door control unit
Driver's seat
(memory)
Convenience
system control
unit
Door control unit,
rear left
Door control unit,
rear right
DSP
CAN Infotainment on CAN convenience control units (physically the same CAN)
are directly connected to the diagnosis plug.
Control units are direct connected to the diagnosis plug via the Gateway.
Drivetrain CAN bus
Convenience CAN bus
Convenience CAN bus
251_057
Engine
control unit
CAN-Infotainment
