25
The Engines
The 1.9-litre 96 kW TDI engine with
pump injection system
The 1.9-litre 96 kW TDI engine differs from 1.9-
litre 74kW TDI engine with pump injection
system in the following respects:
● The software used in the engine control unit
was adapted to the higher engine power.
● The injectors have larger
nozzle holes.
● The
TURBOCHARGER is larger.
● The crankcase is made of stronger material.
● The crank pin diameter of the
crankshaft has been enlarged.
● The conrods are made of stronger material.
Specifications
Engine code AVF
Type In-line engine
Number of cylinders 4
Number of valves per
cylinder
2
Displacement 1896 cm
3
Bore 79.5 mm
Stroke 95.5 mm
Compression ratio 19:1
Max. power 96 kW /130 bhp
4000 rpm
Max. torque 310 Nm
@ 1900 rpm
Engine management
system
BOSCH EDC 15 P
Mixture preparation Direct injection by
pump injection
system
Fuel grades 49 CN diesel,
biodiesel
251_034
251_025
