– Insert air filter upper part into openings for retaining lugs and
secure again with spring retainers -3-.
Note
♦
Ensure that sealing surfaces of air filter housing are seated
properly.
♦
Do not pinch cables or lines.
– Insert bolts of air mass meter -2- and tighten to 3 Nm.
– Fit connector -1- back on air mass meter.
Note
Ensure wiring connector is securely seated.
– Secure coolant line on air filter housing and on connecting
pipe.
– Install engine cover. ⇒ page 70
4.23.3 Removing and installing air filter ele‐
ment, 3.6 l V6 FSI engine.
Removing
– Detach coolant line from air filter housing -2-, unclip from con‐
necting pipe -1- and place to one side.
– Pull off connector -1- of air mass meter.
– Unscrew bolts of air mass meter -2-.
– Open clamps -3-.
Touareg 2010 ➤
Maintenance - Edition 11.2011
54 4. Descriptions of work
