This example shows that the expiry date 05/2003 has been ex‐
ceeded, then the bottle has to be renewed.
– Check the expiry date.
– Renew tyre sealant if the expiry date has been reached.
Caution
♦ The tyre sealant must not be more than 4 years old.
♦ When the bottle has been opened e.g. at a "flat tyre", it
has also to be renewed.
Note
♦ Residual tyre sealant or bottles which are filled and the expiry
date has been exceeded, must be disposed of.
♦ Old tyre sealant or residual sealant must not be mixed and
disposed of with other fluids.
♦ Observe disposal regulations!
4.35 Headlight adjustment: Check halogen
headlights and fog lights, adjust if nec‐
essary
Checking and adjusting prerequisites: ⇒ page 89
Checking headlight adjustment (using test screen without 15°
setting line) ⇒ page 91
Adjusting halogen headlights ⇒ page 92
Fog lights and other additional lights: Adjust ⇒ page 92 .
4.35.1 Checking and adjusting prerequisites:
♦ Tyre inflation pressure OK.
♦ Headlight lenses must not be damaged or dirty.
♦ Reflectors and bulbs OK
♦ Vehicle must be loaded.
♦ The vehicle must be rolled forward or backward several me‐
tres or front and rear springs must be bounced fully several
times so that springs settle.
♦ Vehicle and headlight adjuster must be on a flat surface →
Operating instructions for headlight adjusters VAS 5046, VAS
5047, VAS 5208A, VAS 5209A.
♦ Vehicle and headlight adjuster must be aligned.
♦ Inclination must be set.
Note
For vehicles for North America the side adjustment of headlight
is not permitted and has therefore an adjustment bolt secured
against turning.
Inclination information in „%“ is stamped into trim above headlight.
Headlights must be adjusted according to this information. Per‐
Touareg 2010 ➤
Maintenance - Edition 11.2011
4. Descriptions of work 89
