– Connect electrical connector to air mass meter -arrow-.
Note
Ensure that connector is firmly seated.
– Carry out these steps for left-hand air filter.
– Install engine cover. ⇒ page 70
4.23.5 Removing and installing air filter ele‐
ment, 4.2 l V8 FSI
Removing
Note
Removing and installing the right air filter element is described
below. The left air filter element is removed and installed in the
same manner.
– Detach coolant line from air filter housing -2-, unclip from con‐
necting pipe -1- and place to one side.
– Release hose clamp -1- and pull off connecting pipe -2- from
union.
Touareg 2010 ➤
Maintenance - Edition 11.2011
58 4. Descriptions of work
