Note
♦
PSD means panoramic sliding roof.
♦
Servicing at regular intervals is generally not required for the
panoramic sliding roof.
♦
If during functional check noises occur or when heavily soiled,
clean and grease the surfaces and areas according to the fol‐
lowing description.
♦
The prescribed grease is lithium grease -G 052 147 A2-. Other
types of grease must not be used.
4.29.1 Check function, if necessary clean guide
rails and lubricate with special grease
– Check PSD for damage.
– Check PSD for function and noise.
– Open PSD.
– Clean guide rails below outer seal -A-, -arrows-.
– Apply a thin coat of lithium grease -G 052 147 A2- on all sliding
surfaces of guide rail -arrows-.
-A- Outer seal
-B- Wind deflector
-C- Inner seal
-D- Arrow points in direction of travel.
Note
Ensure that no other components are soiled.
Caution
Faults found must always be rectified (repair measure).
Touareg 2010 ➤
Maintenance - Edition 11.2011
