26
Repair - MS2 reverse gear and upper gear housing, sailboat drive
30. Fix the gear in a vise. Use soft facings on the vise
jaws. Then disassemble hook nut with tool no.
884724.
29. Fix the bearing housing in a vise. Press a screw-
driver into the seal ring. Then place a thick piece of
rubber or leather between the screwdriver and the
bearing housing casting. Prize out the seal ring and
scrap it.
9991801
884728
884724
Input bearing seal housing,
disassembly
27. Remove the circlip, using circlip pliers.
28. Press out the taper roller bearing. Use tool no.
884728 and standard shaft 9991801. Then wash the
gearbox housing out.
