79
Repair - lower gear housing, sailboat drive
75. Secure four of the screws, the ones with holes in
their heads, with locking wire, two screws on each
side as in the illustration.
Other components,
installation
76. Install a new zinc ring.
Tightening torque: 12 Nm (8.85 lbf ft)
77. Change the gasket on the oil drain plug.
IMPORTANT! The gasket must be allowed soak
in oil for about 15 minutes before assembly.
Leakage would otherwise occur.
Pressure test the drive, please refer to the
Pressure
Testing
section.
Fill up with engine oil.
Please refer to
Technical Data
for oil volume, grade
and viscosity.
Check the oil level with the dipstick and install the oil
filler cap.
IMPORTANT! When the drive is installed on the
engine the screws must be dipped in oil (includ-
ing the heads) and torqued.
Tightening torque: 20 Nm (14.75 lbf ft), alternately,
diagonally. Also do an extra
check of tightening.
