15
AB Volvo Penta / Diesel Engine TAMD71B
5 Operation
5.1 Before starting
1. Check that no fuel, water or oil is leaking out.
2. Check engine coolant level (cold engine).
This should be approx. 5 cm (2") below the
seal of the filler cap, or between the MIN and
MAX marks on the separate plastic expan-
sion tank (accessory). See chap. 10.5.2 for
topping up instructions.
Note! Do NOT open the pressure cap on
a hot engine. Steam or hot coolant can
spray out and the system pressure will
be lost.
3. Check the engine oil level. This should be
within the area marked on the dipstick.
The oil level must never be lower than the
bottom mark.
4. Turn on the main switches.
Fig 5.1 Check leaks
Fig. 5.2 Check the coolant level
Fig 5.3 Check the engine oil level
Fig. 5.4 Turn on the main switches
Fig. 5.5 Check the amount of fuel
5. Check the amount of fuel.
