Volvo V70R User Manual

175
Maintenance and service
Battery
1. Battery without cover
2. Battery with cover
Changing the battery
Removing the battery
– Switch off the ignition and remove the
key.
– Wait at least 5 minutes before touching
any electrical terminals. This allows time
for the information in the car’s electrical
system to be stored in the control
modules.
– Undo the screws from the lock brace over
the battery and remove the brace.
– Bend up the plastic cover over the
negative battery terminal or unscrew the
cover from the battery.
– Disconnect the negative battery lead.
– Detach the lower console holding the
battery.
– Bend aside the plastic cover and
disconnect the positive cable.
– Remove the battery.
Fitting the battery
– Fit the battery into position.
– Position the lower console and screw it in
place.
– Connect the positive cable, press in and
fold down the plastic cover.
– Connect the negative cable, fold down
the plastic cover.
– Fit the plastic cover or the cover over the
battery.
– Make sure the evacuation hose is
correctly connected to both the battery
and the outlet in the bodywork.
– Fit the lock brace over the battery and
tighten the screws.
2
1
WARNING!
Batteries can generate oxyhydrogen gas,
which is highly explosive. A spark, which
can be generated if you connect the jump
leads incorrectly, is sufficient to make the
battery explode. The battery also contains
sulphuric acid, which can cause serious
burns. If the acid comes into contact with
eyes, skin or clothing, flush with large
quantities of water. If acid splashes into
the eyes, seek medical advice immedi-
ately.
