OM 75Z3/8003 US – Edition 4.0 * 7003b110.fm 1-7
Introduction
1.5 Regulations
Requirements to be met by the Operator
Earth moving machines may be operated and serviced only by persons who meet the fol-
lowing requirements:
• 18 years or older
• Physically and mentally suited for this work
• Persons have been instructed in operating and servicing the earth moving machine and
have proven their qualifications to the contractor.
• Persons are expected to perform work reliably.
• They have been assigned by the contractor for operating and servicing the earth
moving machine.
• Get informed on and follow the legal regulations of your country.
Backhoe bucket B = 600 mm (24 in)
189 kg (417 lbs)
0.221 m
3
(7.8 ft³)
157 kg (346 lbs) Mechanical quickhitch
186 kg (410 lbs)
0.220 m
3
(7.8 ft³)
Hydraulic quickhitch (Easy Lock)
Backhoe bucket B = 700 mm (28 in) 204 kg (450 lbs)
0.256 m
3
(9 ft³)
Hydraulic quickhitch (Easy Lock)
Backhoe bucket B = 750 mm (30 in)
216 kg (476 lbs)
0.279 m
3
(9.9 ft³)
182 kg (401 lbs) Mechanical quickhitch
Backhoe bucket B = 800 mm (32 in) 228 kg (503 lbs)
0.292 m
3
(10.3 ft³)
Hydraulic quickhitch (Easy Lock)
Backhoe bucket B = 900 mm (35 in)
238 kg (525 lbs)
0.339 m
3
(12 ft³)
206 kg (454 lbs) Mechanical quickhitch
246 kg (542 lbs)
0.328 m
3
(11.6 ft³)
Hydraulic quickhitch (Easy Lock)
Backhoe bucket B = 1.0 m (39 in) 264 kg (582 lbs)
0.365 m
3
(12.9 ft³)
Hydraulic quickhitch (Easy Lock)
Ditch cleaning bucket B = 1.2 m (47 in)
195 kg (430 lbs)
0.241 m
3
(8.5 ft³)
300 kg (661 lbs) Mechanical quickhitch
Ditch cleaning bucket B = 1.5 m (59 in)
225 kg (496 lbs)
0.314 m
3
(11.1 ft³)
295 kg (650 lbs) Mechanical quickhitch
238 kg (525 lbs)
0.342 m
3
(12.1 ft³)
Hydraulic quickhitch (Easy Lock)
Offset bucket B = 1.5 m (59 in)
325 kg (716 lbs)
0.280 m
3
(9.9 ft³)
280 kg (617 lbs) Mechanical quickhitch
358 kg (789 lbs)
0.342 m
3
(12.1 ft³)
Hydraulic quickhitch (Easy Lock)
Description of attachment Weight Capacity Remarks
