Technical Data
16.1 General instructions
56
Operator’s manual | AS | 5100056974 | 06/2020 | [us]
16 Technical Data
16.1 General instructions
Information
For system technical reasons, empty columns can be displayed in the
technical data, and numbers and letters that written in superscript or sub-
script may be displayed incorrectly, e.g:
► Sound power level LWA instead of L
WA
► Sound pressure level LpA instead of L
pA
► Vibration total value ahv instead of a
hv
► Carbon dioxide CO2 instead of CO
2
► Unit m/s2 instead of m/s
2
16.2 Noise and vibration data
The noise and vibration data listed have been determined in accordance
with the following guidelines for the typical machine operating conditions /
special test conditions and using harmonized standards:
• Machinery Directive 2006/42/EC
• Noise Emission Directive 2000/14/EC
During operational use, values may differ depending on the prevailing op-
erating conditions.
Sound pressure level at operator station
• L
pA
was determined according to EN ISO 11201 and EN 500-4.
Guaranteed sound power level
• L
WA
was determined according to EN ISO 3744 and EN ISO -4.
Weighted vibration total value hand-arm vibration
• a
hv
was determined according to EN ISO 20643 and EN 500-4.
16.3 Machine
Type AS30e AS50e
Material number 5100026851 5100053792
Rated current [A] 26,30 41,00
Rated voltage [V] 51 51
Rated ouput [kW] 1,34 2,10
Type of current (output) Direct current (DC) Direct current (DC)
Number of strokes [1/min] 810 680
Forward travel [m/min] 11,00 11,40
Impact force [kN] 10 16
Length [mm] 620 610
