Technical Data
16.4 Rechargeable battery
58
Operator’s manual | AS | 5100056974 | 06/2020 | [us]
Type AS60e
Engine type Asynchronous engine
Insulation class F
Rated ouput [kW] 2,120
Rated torque [Nm] 3,500
Rated speed [1/min] 4.350
Recommended battery type BP1000; BP1400
Special lubricants SAE 10W30
Relubrication interval [h] 250
Oil specifications (Ramming system) SAE 10W40
Oil volume (Ramming system) [l] 0,700
Protection type IP23D
Operating temperature range [°C] 0 – +45
Storage temperature range [°C] -30 – +50
Sound pressure level LpA [dB(A)] 92
Sound power level LWa measured [dB(A)] 105
Sound power level LWa guaranteed [dB(A)] 108
Vibration total value ahv [m/s2] 8,3
Measurement uncertainty of the total vibration value
ahv [m/s2]
2,2
* The actual operating speed depends on numerous operating parameters and may differ from the rated speed.
16.4 Rechargeable battery
Type BP1000 BP1400
Material number 5100025709 5100048620
Rated voltage [V] 51 51
Type of current (output) Direct current (DC) Direct current (DC)
Length [mm] 220 220
Width [mm] 290 290
Height [mm] 197 197
Weight [kg] 9,4 9,6
Range per battery charge [m] AS30e 572 770
Range per battery charge [m] AS50e 342 456
Range per battery charge [m] AS60e 278 363
Battery label 14INR19/65-8 14INR19/65-8
Battery type Lithium-Ionen Lithium-Ionen
Energy content [Wh] 1.008 1.411
Capacity [Ah] 20 28
Discharge current max. [A] 160 80
Charge current max. [A] 32 27
Protection type IP2X IP2X
Storage temperature range [°C] -30 – +50 -30 – +50
Operating temperature range [°C] -10 – +50 -10 – +50
