Technical Data
Battery charger 16.5
59
[us] | 06/2020 | 5100056974 | AS | Operator’s manual
Type BP1000 BP1400
Operating temperature range charging [°C] 0 – +45 0 – +45
16.5 Battery charger
Type C48/4
Material number 5100006221
Rated voltage [V] 230 (90 – 265)
Type of current (input) Alternating current 1~
Rated current [A] <3
Rated frequency [Hz] 50 – 60
Type of current (output) DC
Output current [A] 4 +/-0,5
Output voltage max. [V] 57,6
Length [mm] 190
Width [mm] 145
Height [mm] 65
Weight [kg] 2,0
Power cable [mm] 1500
Supply cable [mm] 1800
Protection class II
Protection type IP54
Storage temperature range [°C] -30 - +50
Operating temperature range [°C] 0 - +45
16.6 Extension cable
• Only use permissible extension cables, .
• Data on the type designation and voltage of this machine can be
found on the type label.
• Refer to the following table for the required wire cross-section of the
extension cable:
Type C48/4
Material number 5100006221
Extension [m] ≤150
Strand cross section [mm2] 1,5
16.7 Conversion table
The following conversion tables enable the conversion of the metric val-
ues from the instructions, in particular the technical data, into the impe-
rial.
Conversion table
Volume units
16
