BS 50-2 Operation
4.3 Refueling the Machine
Requirements
Machine shut down
Engine cool
Machine standing upright on the ramming shoe
Fresh, clean fuel supply
Procedure
Perform the procedure below to refuel the machine.
1. Remove the fuel cap (a).
2. Fill the fuel tank until the fuel level reaches the bottom of the fuel tank neck (b).
3. Reinstall the fuel cap.
Result
The machine has now been refueled.
WARNING
Fire and burn hazard. Fuel and its vapors are extremely flammable.
f Keep all sources of ignition away from the machine while refueling.
f Do not refuel if the machine is positioned in a truck fitted with a plastic bed liner.
Static electricity can ignite the fuel or fuel vapors.
f Refuel only when the machine is outdoors.
f Clean up spilled fuel immediately.
wc_gr008408
a
b
CAUTION
Fire and health hazard. Fuel expands when heated. Expanding fuel in an over-filled
tank can lead to spills and leaks.
f Do not overfill the fuel tank.
