Technical Data Rammer Repair

144 wc_td000112gb.fm

10.13 BS 600/700 High Altitude

Item Number:

BS 600

0009077

BS 700

0009079

Rammer

Engine Model

type WM80

Engine Speed - full

rpm 4350 ± 100

Engine Speed - idle

rpm 1800 ± 100

Clutch Engagement

rpm 2800 ± 100

Spark Plug

type Champion RL95YC

Electrode Gap

mm (in.) 0.5 (0.020)

Cylinder Head

Compression (cold)

bar/cm

(psi)

8.0–9.7 (120–140)

Air Cleaner

type Dual Element

Engine Lubrication

oil grade With standard two-cycle oil - use 50:1 ratio.

With Wacker Neuson two-cycle or two-cycle oil per NMMA

TC-W3, API TC, JASO FC or ISO EGD specifications - 100:1

or 50:1 ratio.

Ramming System

Lubrication

oil grade SAE 10W30

Ramming System

Capacity

ml (oz.) 890 (30)
