PRODUCT SPECIFICATIONS
GENERAL SPECIFICATIONS FOR ALL INTUOS2 TABLETS
Coordinate resolution 100 lpmm (2540 lpi)
Accuracy (pen) +/- 0.25 mm (0.010 in)
Accuracy (Lens Cursor) +/- 0.15 mm (0.006 in), +/- 0.25 mm (0.010 in) on Intuos2 4x5/A6, 6x8/A5, and
9x12/A4-regular tablets
Tilt +/- 60 degrees, +/- 50 degrees for Intuos2 4x5/A6 tablets
Maximum reading height with pen 6 mm (0.24 in)
Maximum report rate 200 points per second
Communication interface USB
Connector USB A
Power requirements (USB tablets) DC 5V, less than 140mA, from primary USB port or powered USB hub
Operating temperature 5 to 40 degrees C (41 to 104 degrees F)
Storage temperature -10 to +60 degrees C (14 to 140 degrees F)
Operating relative humidity 20% to 80% noncondensing
Storage relative humidity 20% to 90% noncondensing
Certification and compliance FCC Class B, VCCI Class B, CE
