Item Part No. Description Qty.

1 9822 604 Locking ring 1

2 0291 304 Housing, upper part 1

3 9830 107 Cylinder pin 1

4 0291 515 Piston 1

5 9894 229** Pressure spring 1

6 0258 323 Ball bearing traveller 1

7 9870 113** Seal 1

8 9841 502** Ball 10 1

9 0294 516** Valve face 1

12 0123 328 Valve screw 1

13 0291 403 Supporting ring 1

14 0111 456* Packing, PE 3

15 0291 376* Packing, leather 2

16 0291 355* Pressure ring 1

17 9894 223* Spring washer 1

18 0291 391 Bush 1

20 9971 452* O-ring 42 x 1.5 1

21 9971 453* O-ring 51 x 2 1

22 0010 754 Screwed socket, NPSM 3/8 – M 16 x 1.5 1

23 9970 103 Sealing ring 1

25 0291 350 Cylinder, upper part 1

26 9894 224* Spring washer 1

27 0291 412* Pressure ring 1

28 0111 452* Packing, PE 3

29 0291 377* Packing, leather 2

30 0291 417 Supporting ring 1

31 9971 451*(**) O-ring 55 x 2 1

32 0291 353 Cylinder, lower part 1

34 0279 462 Spring rest 1

35 0037 776*** Pressure spring 1

36 0258 319*** Ball 25.4 1

37 0169 406*** Valve face 1

38 9971 434*(***) O-ring 48 x 2 1

39 0291 483 Valve housing 1

0256 701* Service-Set, packings

0258 721** Service-Set, outlet valve

0258 722*** Service-Set, intake valve

Spare parts list – material feed pump (Spare parts diagram, see page 67)
