Part Number 550-110-639/0512
35
EG
•
PEG
•
EGH Gas-firEd boilErs — sEriEs 4 — boilEr manual
Replacement parts — EGH
Table 14 EGH replacement parts
Item Description Boiler
Models
Part Number
J
1
Back burner support EGH-85 451-800-095
EGH-95 451-800-096
EGH-105 451-800-097
EGH-115 451-800-098
EGH-125 451-800-099
L
1
Cover plate for heater opening (rectangular) — 389-900-103
L
2
Gasket for cover plate (rectangular) — 590-317-579
L
3
Cover plate for heater opening (round) — 389-900-101
L
4
Gasket for cover plate (round) — 590-317-495
Section assembly, complete with heater opening (not
shown)
EGH-85 321-711-100
Section assembly, complete without heater opening (not
shown)
EGH-85 321-711-105
Section assembly, complete with heater opening (not
shown)
EGH-95 321-711-110
Section assembly, complete without heater opening (not
shown)
EGH-95 321-711-115
Section assembly, complete with heater opening (not
shown)
EGH-105 321-711-120
Section assembly, complete without heater opening (not
shown)
EGH-105 321-711-125
Section assembly, complete with heater opening (not
shown)
EGH-115 321-711-130
Section assembly, complete without heater opening (not
shown)
EGH-115 321-711-135
Section assembly, complete with heater opening (not
shown)
EGH-125 321-711-140
Section assembly, complete without heater opening (not
shown)
EGH-125 321-711-145
Section replacement kit (includes 3” and 6” elastomer
seal, 2 pieces of rope, tube of silicone, order 1 per joint
between sections)
(not shown)
— 381-800-667
Burner shields (rollout) EGH-85 451-800-120
EGH-95 451-800-121
EGH-105 451-800-122
EGH-115 451-800-123
EGH-125 451-800-124
Sealer for sections (2 pieces of rope, tube of silicone
per joint between sections) (not shown)
— 591-641-865
¹⁄₂” x 7” Tie rod w/o nut (2 per boiler) (not shown)
— 560-234-465
¹⁄₂” x 17” Tie rod w/o nut (4 – EGH-85)
(not shown) (2 – EGH-95)
— 560-234-472
¹⁄₂” x 21¹⁄₄” Tie rod w/o nut (2 – EGH-95)
(not shown) (2 – EGH-115)
(4 – EGH-125)
— 560-234-477
¹⁄₂” x 25¹⁄₄” Tie rod w/o nut (2 – EGH-115)
(not shown) (4 – EGH-125)
— 560-234-482
¹⁄₂” Nut (2 per tie rod) — 561-928-221
¹⁄₂” Lock washer (1 per tie rod) — 562-248-668
Retort cement (1 quart) — 591-602-913
Flue brush (not shown) — 591-706-214
Note 1: Order sufficient quantities to replace all orifices within a base.
Item Description Boiler
Models
Part Number
A Left hand end section with heater opening (Pattern No.
1814)
— 311-800-014
Left hand end section without heater opening (Pattern
No. 1813)
— 311-800-007
B Right hand end section with heater opening (Pattern No.
1819)
— 311-800-022
Right hand end section without heater opening with
control tappings (Pattern No. 18118)
— 311-800-032
C Intermediate section (Pattern No. 1815) — 311-800-010
Intermediate section with tie rod lugs (Pattern No. 1817) — 311-800-026
C
1
3” Diameter bottom elastomer seal (1 per joint) — 592-800-010
6” Diameter top elastomer seal (1 per joint) — 592-800-007
D Draft hood EGH-85 450-206-240
EGH-95 450-206-241
EGH-105 450-206-242
EGH-115 450-206-243
EGH-125 450-206-244
E Collector hood EGH-85 450-014-750
EGH-95 450-014-751
EGH-105 450-014-752
EGH-115 450-014-753
EGH-125 450-014-754
F Burner, stainless tube, regular — 512-200-000
F
1
Burner, stainless tube, with pilot bracket — 512-200-001
G Manifold EGH-85 591-125-543
EGH-95 591-125-544
EGH-105 591-125-545
EGH-115 591-125-546
EGH-125 591-125-547
Main burner orifice, natural gas, 2.45mm (note 1) — 560-528-987
Main burner orifice, propane gas, 1.55mm (note 1) — 560-528-988
H Front base panel (in base panel carton) — —
H1 Front base insulation (in base panel carton) — —
H
2
Base front access panel (in base panel carton) — —
H, H
1
,
H
2
, I,
I
1
& I
2
Base panel carton EGH-85 381-700-240
EGH-95 381-700-245
EGH-105 381-700-250
EGH-115 381-700-255
EGH-125 381-700-260
I Back base panel (in base panel carton) — —
I
1
Back base insulation (in base panel carton) — —
I
2
Back base channel (in base panel carton) — —
J Side rail for burner panel with bracket for burner pan — 451-800-070
