Weishaupt WG20-/1-C LN Series User Manual

Installation and operating instruction
Gas burner WG20…/1-C LN
7 Commissioning
83240802 1/2020-01 La
39-96
7.1.6 Setting values
Set mixing head relative to the combustion heat rating required. For this, the dif-
fuser setting and the air damper setting should be matched.
Determine diffuser setting and air damper setting
Do not operate the burner outside of the capacity graph [ch.3.4.6].
Determine the diffuser setting (dimension X) and air damper setting required
from the diagram and note down.
Example
Burner capacity required 160 kW
Diffuser setting (dimensionX) 9.2 mm
Air damper setting 7.3
Diffuser default settings
2
1
4
6
8
10
12
14
16
2
0
70
80
100
120
140
180
90
110
130
170
210
190
200
150
160
1 Combustion heat rating [kW]
2 Diffuser settings (dimension X) [mm]
Air damper default settings
2
1
4
5
6
7
8
9
10
3
70
80
100
120
140
180
90
110
130
150
170
210
190
200
160
1 Combustion heat rating [kW]
2 Air damper setting
