Weishaupt WG20-/1-C LN Series User Manual

Installation and operating instruction
Gas burner WG20…/1-C LN
11 Technical documentation
83240802 1/2020-01 La
72-96
11 Technical documentation
11.1 Wiring diagram
For special version observe wiring diagram supplied.
T1
T2
S3
B4
X6
P
P
F7
F7
F2
P6
P11
B15
L PE N
S1
L
PE
N
P
B10
X3:11X3:2
F1
X3:3
C1
M1
M
~
X3:12
B31
P
L1
PE
N
L2
1
2
3
X8
W-FM 05
K1
K3
K2
5
4
6
3
2
12
11
13
X6
X3:
F7
W-FM 05
C1 Motor capacitor
F1 External fuse (max 16 AB)
F2 Temperature or pressure limiter
F7 Internal unit fuse (T6.3H, IEC 127-2/5)
B10 Air pressure switch
B31 Low gas pressure switch
B15 Temperature or pressure regulator
P6 Control lamp lockout (optional)
P11 Control lamp operation (optional)
M1 Burner motor
S1 Operating switch
