Front Panel (AC End)
2–3
Front Panel (AC End)
The front panel of the PROwatt 3000 can be configured in two ways:
• PROwatt 3000 is equipped with one 15 A circuit breaker-protected
receptacle on the front panel as shown in Figure 2-1. You can connect
loads to this receptacle.
• To derive maximum power from the PROwatt 3000, you can remove
the receptacle and hardwire the inverter to an AC source panel
through the front panel as shown in Figure 2-2. (For AC wiring
procedures, see “Connecting to an Existing AC Circuit” on page 3–
6.)
