Xerox ColorQube 8880 Service Manual

September 2014
5-11
ColorQube 8570/8870/8580/8880 Service Manual
Xerox Supplies and Accessories
Parts Lists
Initial Issue - Xerox Internal Use Only
Xerox Supplies and Accessories
Table 1 Consumables and Routine Maintenance Items
Description Part Number
Xerox ColorQube Ink (C), ColorQube 8570/8580 (2 Sticks), North America 108R00926
Xerox ColorQube Ink (M), ColorQube 8570/8580 (2 Sticks), North America 108R00927
Xerox ColorQube Ink (Y), ColorQube 8570/8580 (2 Sticks), North America 108R00928
Xerox ColorQube Ink (K), ColorQube 8570/8580 (2 Sticks), North America 108R00929
Xerox ColorQube Ink (K), ColorQube 8570/8580 (4 Sticks), North America 108R00930
Xerox ColorQube Ink (C), ColorQube 8570/8580 (2 Sticks), Europe 108R00931
Xerox ColorQube Ink (M), ColorQube 8570/8580 (2 Sticks), Europe 108R00932
Xerox ColorQube Ink (Y), ColorQube 8570/8580 (2 Sticks), Europe 108R00933
Xerox ColorQube Ink (K), ColorQube 8570/8580 (2 Sticks), Europe 108R00934
Xerox ColorQube Ink (K), ColorQube 8570/8580 (4 Sticks), Europe 108R00935
Xerox ColorQube Ink (C), ColorQube 8570/8580 (2 Sticks), DMO 108R00936
Xerox ColorQube Ink (M), ColorQube 8570/8580 (2 Sticks), DMO 108R00937
Xerox ColorQube Ink (Y), ColorQube 8570/8580 (2 Sticks), DMO 108R00938
Xerox ColorQube Ink (K), ColorQube 8570/8580 (2 Sticks), DMO 108R00939
Xerox ColorQube Ink (K), ColorQube 8570/8580 (4 Sticks), DMO 108R00940
Xerox ColorQube Ink (C), ColorQube 8570/8580 (2 Sticks), Asia Pacific 108R00941
Xerox ColorQube Ink (M), ColorQube 8570/8580 (2 Sticks), Asia Pacific 108R00942
Xerox ColorQube Ink (Y), ColorQube 8570/8580 (2 Sticks), Asia Pacific 108R00943
Xerox ColorQube Ink (K), ColorQube 8570/8580 (2 Sticks), Asia Pacific 108R00944
Xerox ColorQube Ink (K), ColorQube 8570/8580 (4 Sticks), Asia Pacific 108R00945
Xerox ColorQube Ink Metered (C), ColorQube 8570/8580 (4 Sticks) 108R00946
Xerox ColorQube Ink Metered (M), ColorQube 8570/8580 (4 Sticks) 108R00947
Xerox ColorQube Ink Metered (Y), ColorQube 8570/8580 (4 Sticks) 108R00948
Xerox ColorQube Ink Metered (K), ColorQube 8570/8580 (4 Sticks) 108R00949
Xerox ColorQube Ink (C), ColorQube 8870/8880 (6 Sticks), North America 108R00950
Xerox ColorQube Ink (M), ColorQube 8870/8880 (6 Sticks), North America 108R00951
Xerox ColorQube Ink (Y), ColorQube 8870/8880 (6 Sticks), North America 108R00952
Xerox ColorQube Ink (K), ColorQube 8870/8880 (6 Sticks), North America 108R00953
Xerox ColorQube Ink (C), ColorQube 8870/8880 (6 Sticks), Europe 108R00954
Xerox ColorQube Ink (M), ColorQube 8870/8880 (6 Sticks), Europe 108R00955
Xerox ColorQube Ink (Y), ColorQube 8870/8880 (6 Sticks), Europe 108R00956
Xerox ColorQube Ink (K), ColorQube 8870/8880 (6 Sticks), Europe 108R00957
Xerox ColorQube Ink (C), ColorQube 8870/8880 (6 Sticks), DMO 108R00958
Xerox ColorQube Ink (M), ColorQube 8870/8880 (6 Sticks), DMO 108R00959
Xerox ColorQube Ink (Y), ColorQube 8870/8880 (6 Sticks), DMO 108R00960
Xerox ColorQube Ink (K), ColorQube 8870/8880 (6 Sticks), DMO 108R00961
Xerox ColorQube Ink Metered (C), ColorQube 8870/8880 (6 Sticks) 108R00962
Xerox ColorQube Ink Metered (M), ColorQube 8870/8880 (6 Sticks) 108R00963
Xerox ColorQube Ink Metered (Y), ColorQube 8870/8880 (6 Sticks) 108R00964
Xerox ColorQube Ink Metered (K), ColorQube 8870/8880 (6 Sticks) 108R00965
Maintenance Kit, Standard Capacity, ColorQube 8570/8580/8870/8880 109R00784
Maintenance Kit, Extended Capacity, ColorQube 8570/8580/8870/8880 109R00783
Waste Tray 109R00754
Rainbow Pack 058K00250
Table 2 Options
Description Part Number
525-Sheet Feeder 059K76570
Printer Cart 137E11900
Wireless Network Adapter with NA power converter 110V 097S03740
Wireless Network Adapter with Euro power converter 220V 097S03741
Wireless Network Adapter with UK power converter 220V 097S03742
Productivity Kit (Includes MSATA SSD Card), ColorQube 8580/8880 097S04674
Productivity Kit (Includes 2GB DDR3 Card), ColorQube 8580/8880 097S04672
N to DN Upgrade, ColorQube 8580 097S04673
Productivity Kit (Includes Hard Drive), ColorQube 8570/8870 097S04141
1GB Memory, ColorQube 8570/8870 097S04025
512 MB Memory, ColorQube 8570/8870 097S03635
Table 3 Power Cords
Description Part Number
Power Cord, North America (NEMA 5-15), 115V, 13A 117E35170
Power Cord, Euro, 230V 117E29500
Power Cord, UK, 240V 117E29510
Power Cord, Australia, 230V 117E29490
Power Cord, Switzerland, 230V 117E35050
Power Cord, Denmark, 230V 117E29460
Power Cord, China, 220V 117E35030
Power Cord, Argentina, 220V 117E35040
Power Cord, Italy, 230V 117E29450
Power Cord, Israel, 230V 117E29480
Power Cord, India/ South Africa, 230V 117E29470
Table 4 Kits and Other Items
Description Part Number
Mechanical Hardware Kit 604K42210
Repackaging Kit 695K22810
Grease, Nye Rheolube 368F 070E00890
Tool, Screwdriver, Torque, Adjust 003082700
Table 1 Consumables and Routine Maintenance Items
Description Part Number

Xerox ColorQube 8880 Specifications

General

Color	Yes
Maximum duty cycle	120000 pages per month
Number of print cartridges	1
Page description languages	PCL 5Ce, TIFF
Maximum resolution	2400 x 1200 DPI
Time to first page (color, normal)	5 s
Print speed (color, draft quality, A4/US Letter)	51 ppm
Print speed (black, normal quality, A4/US Letter)	- ppm
Print speed (color, normal quality, A4/US Letter)	30 ppm
Maximum internal memory	2048 MB
Total input capacity	625 sheets
Total output capacity	350 sheets
Total number of input trays	5
Multi-Purpose tray input capacity	100 sheets
Paper tray media types	Thin paper
Maximum ISO A-series paper size	A4
Wi-Fi	No
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Linux operating systems supported	RedHat EL Linux 4.0 U5
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)	- W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	ENERGY STAR
Product color	White
Market positioning	Business

Weight and Dimensions

Depth	521 mm
Width	406 mm
Height	368 mm
