Troubleshooting
WorkCentre 7500 Series Multifunction Printer 225
User Guide
Troubleshooting Paper Jams
This section includes:
 Multiple Sheets Pulled Together .................................................................................................................................. 225
 Paper Misfeeds .................................................................................................................................................................... 225
 Jams in the Document Feeder ...................................................................................................................................... 226
 Paper Jam Message Stays On ....................................................................................................................................... 226
 Duplex Unit Jams ...............................................................................................................................................................226
Multiple Sheets Pulled Together
Probable Causes Solutions
The paper tray is too full. Remove some of the paper. Do not load paper past fill line.
The edges of the paper are not even. Remove the paper, align the edges, and then reload it.
The paper is moist from humidity. Remove the paper from the tray, and replace it with new dry paper.
Too much static electricity is present.  Try a new ream of paper.
 Do not fan transparencies before loading in tray.
Using unsupported paper. Use only Xerox
®
-approved paper. For details, see Supported Paper
on page 38.
Humidity is too high for coated paper. Feed paper one sheet at a time.
Paper Misfeeds
Probable Causes Solutions
The paper is not correctly positioned in the
tray.
 Remove the misfed paper and reposition it properly in the tray.
 Ensure that the paper guides in the tray are set correctly.
The paper tray is too full. Remove some of the paper. Do not load paper past fill line.
The paper guides are not correctly adjusted to
the media size.
Adjust the paper guides in the tray to match the size of the media.
Warped or wrinkled paper is loaded in the
tray.
Remove the paper, smooth it out, and reload it. If it still misfeeds, do
not use that paper.
The paper is moist from humidity. Remove the moist paper and replace it with new, dry paper.
Unsupported paper of the wrong size,
thickness, or type.
Use only Xerox
®
-approved paper. For details, see Supported Paper
on page 38.

Xerox WorkCentre 7535 Specifications

General

Duplex printing	Yes
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	8.6 s
Time to first page (color, normal)	11 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	Scan
Digital sender	No
Maximum duty cycle	110000 pages per month
Page description languages	HP-GL/2, PCL 5c, PCL 6, PostScript 3
Copier resize	25 - 400 %
Copy speed (black, normal quality, A4)	35 cpm
Image formats supported	JPG, TIF
Document formats supported	PDF
Optical scanning resolution	- DPI
Total input capacity	520 sheets
Total output capacity	500 sheets
Maximum input capacity	5140 sheets
Maximum print size	297 x 420 mm
Paper tray media types	Bond paper, Envelopes, Glossy paper, Labels, Plain paper, Transparencies
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Display	LCD
Market positioning	Business
Direct printing	-
Standard interfaces	USB 2.0
Internal memory	3000 MB
Internal storage capacity	160 GB
Sound pressure level (printing)	58 dB
AC input voltage	100 - 120 V
AC input frequency	50 - 60 Hz
Power consumption (average operating)	984 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Faxing	Mono faxing

Weight and Dimensions

Depth	685 mm
Width	1064 mm
Height	1127 mm
