Xilinx Alveo U50 Installation Guide

1. Enter the following command:
$ sudo lspci -vd 10ee:
2. If the card is successfully installed and found by the operang system, you will see a message
similar to the following. Note that for each card, there will be two physical funcons found:
one for management and one for user. See hps://xilinx.github.io/XRT/master/html/
plaorms.html for addional details.
65:00.0 Processing accelerators: Xilinx Corporation Device 5020
Subsystem: Xilinx Corporation Device 000e
Flags: bus master, fast devsel, latency 0
Memory at 38bff2000000 (64-bit, prefetchable) [size=32M]
Memory at 38bff4020000 (64-bit, prefetchable) [size=128K]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable+ Count=32 Masked-
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [1c0] #19
Capabilities: [e00] Access Control Services
Capabilities: [e10] #15
Capabilities: [e80] Vendor Specific Information: ID=0020 Rev=0
Len=010 <?>
Kernel driver in use: xclmgmt
Kernel modules: xclmgmt
65:00.1 Processing accelerators: Xilinx Corporation Device 5021
Subsystem: Xilinx Corporation Device 000e
Flags: bus master, fast devsel, latency 0, IRQ 183
Memory at 38bff0000000 (64-bit, prefetchable) [size=32M]
Memory at 38bff4000000 (64-bit, prefetchable) [size=128K]
Memory at 38bfe0000000 (64-bit, prefetchable) [size=256M]
Capabilities: [40] Power Management version 3
Capabilities: [60] MSI-X: Enable+ Count=32 Masked-
Capabilities: [70] Express Endpoint, MSI 00
Capabilities: [100] Advanced Error Reporting
Capabilities: [e00] Access Control Services
Capabilities: [e10] #15
Capabilities: [e80] Vendor Specific Information: ID=0020 Rev=0
Len=010 <?>
Kernel driver in use: xocl
Kernel modules: xocl
Running xbmgmt flash --scan
Use the xbmgmt flash --scan command to display and conrm the card's ashed rmware
version and the installed card details, including the card Bus:Device:Funcon (BDF), plaorm
name, and ID.
1. Enter the following command:
$ sudo /opt/xilinx/xrt/bin/xbmgmt flash --scan
Chapter 5: Card Bring-Up and Validation
UG1370 (v1.7) December 9, 2020 www.xilinx.com
Alveo U50 Data Center Accelerator Card Installation Guide 26
Send Feedback
