Xilinx VCU1525 User Manual

VCU1525 Acceleration Platform User Guide 44
UG1268 (v1.0) November 13, 2017 www.xilinx.com
Chapter 3: Board Component Descriptions
V
CCINT
(0.85V nom.), V
CCAUX
(1.8V nom.), and V
CCBRAM
(0.85V nom.) rail voltages can be
displayed via the SYSMON internal voltage measurement capability.
Board Management Controller Voltage Measurements
The VCU1525 MSP432 U19 board management controller ADC interface allows additional
power system voltage measuring capability. The VCU1525 voltage rail-to-ADC channel
assignments are listed in Table 3-10.
Table 3-10: MSP432 U19 ADC Channel Assignments
Rail Net Name
MSP432 U19
Pin# Name
12V_PEX ADC0 69 P5_5/A0
3V3_PEX ADC1 68 P5_4/A1
3V3AUX ADC2 67 P5_3/A2
12V_AUX ADC3 66 P5_2/A3
DDR4_VPP_BTM ADC4 65 P5_1/A4
SYS_5V5 ADC5 64 P5_0/A5
VCC1V2_TOP ADC6 63 P4_7/A6
VCC1V8 ADC7 62 P4_6/A7
VCC0V85 ADC8 61 P4_5/A8
SPI0_WPn ADC9 60 P4_4/A9
MGT0V9AVCC ADC10 59 P4_3/A10
VCCINT ADC11 58 P4_2/A11
MGTAVTT ADC12 57 P4_1/A12
ADC_USR ADC13 56 P4_0/A13
12V_AUX_VIN ADC14 55 P6_1/A14
DDR4_VPP_TOP ADC15 54 P6_0/A15
VCC1V2_BTM ADC16 53 P9_1/A16
VIN_VCC1V8_MGTAVCC ADC17 52 P9_0/A17
VIN_VCC0V85 ADC18 51 P8_7/A18
12V_SW ADC19 50 P8_6/A19
3V3PEX_I_IN ADC20 49 P8_5/A20
12VPEX_I_IN ADC21 48 P8_4/A21
VIN_VCC1V2 ADC22 47 P8_3/A22
VIN_MGTAVTT ADC23 46 P8_2/A23
