VCU1525 Acceleration Platform User Guide 47

UG1268 (v1.0) November 13, 2017 www.xilinx.com

Appendix A

Master Constraints File Listing

Overview

The master Xilinx® design constraints (XDC) file template for the VCU1525 board provides

for designs targeting the VCU1525 reconfigurable acceleration platform. Net names in the

constraints listed correlate with net names on the latest VCU1525 board schematic. You

must identify the appropriate pins and replace the net names with net names in the user

RTL. See the Vivado Design Suite User Guide: Using Constraints (UG903) [Ref 11] for more

information.

For detailed I/O standards information required for a particular interface, see the constraint

files generated by tools such as the memory interface generator (MIG) and the base system

builder (BSB).

# CLOCKS

# SYSCLK

set_property PACKAGE_PIN AY38 [get_ports SYSCLK0_300_N];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK0_300_N];

set_property PACKAGE_PIN AY37 [get_ports SYSCLK0_300_P];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK0_300_P];

set_property PACKAGE_PIN AW19 [get_ports SYSCLK1_300_N];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK1_300_N];

set_property PACKAGE_PIN AW20 [get_ports SYSCLK1_300_P];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK1_300_P];

set_property PACKAGE_PIN E32 [get_ports SYSCLK2_300_N];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK2_300_N];

set_property PACKAGE_PIN F32 [get_ports SYSCLK2_300_P];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK2_300_P];

set_property PACKAGE_PIN H16 [get_ports SYSCLK3_300_N];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK3_300_N];

set_property PACKAGE_PIN J16 [get_ports SYSCLK3_300_P];

set_property IOSTANDARD DIFF_SSTL12 [get_ports SYSCLK3_300_P];

# USER_SI570_CLOCK

set_property PACKAGE_PIN AV19 [get_ports USER_SI570_CLOCK_N];

set_property IOSTANDARD LVDS [get_ports USER_SI570_CLOCK_N];

set_property PACKAGE_PIN AU19 [get_ports USER_SI570_CLOCK_P];

set_property IOSTANDARD LVDS [get_ports USER_SI570_CLOCK_P];

# EMMCLK

set_property PACKAGE_PIN AK13 [get_ports FPGA_CCLK];

set_property IOSTANDARD LVCMOS18 [get_ports FPGA_CCLK];
