5.4.4 Speed control (external analog value)
P0-01 Control mode selection
Set to 4: external analog value
P3-00 Analog voltage
corresponding to rated speed
Set the speed command voltage required to run the
servo motor at rated speed, unit: 0.001V
P3-09 Soft start acceleration time
P3-10 Soft start deceleration time
Set the acceleration deceleration time, unit ms
P3-02 analog voltage speed filter
P3-03 speed command input dead
time voltage
P3-04 analog speed direction
switching
Switch the input direction of analog speed command
5.4.4.1 External analog speed mode
Speed control: external analog value
Function: speed command is given by external analog quantity. The analog voltage command input
from the V-REF terminal is given as the speed control signal to control the speed.
Note:
(1) Direction switching: positive and negative voltage or SPD-D (P5-27) can control direction.
(2) Refer to section 3.2.4 analog input circuit for hardware wiring.
5.4.4.2 Analog value corresponding to rated speed
V-REF function
distribution
Analog quantity
corresponding to rated
speed
Function description: set the speed command voltage (V-REF) required to run the servo motor at rated
speed.
For example, P3-01 = 5000, indicating that when the analog input voltage is 5.00V, the motor operates
at the rated speed;
P3-01 = 8000, indicating that when the analog input voltage is 8.00V, the motor operates at the rated
speed.
