Xinje TS Series User Manual

2
(3) Communication
◆ Dual port independent communication, which can connect multiple different devices at the same time.
◆ Equipped with Ethernet interface to support communication with Ethernet equipment, Siemens
S7-1200, Siemens S7-200 Smart and other Modbus TCP equipment.
◆ The printer can be directly driven, which is economical and flexible.
◆ Support free format communication, and end users can write drivers freely.
◆ Covering mainstream information interaction protocols and support MQTT/TCP IP communication.
2-1-2. Naming rule



700
TS5L
M
①：
Series
TS5L series
②：
Size
700: 7.0 inch
1000: 10.1 inch
③：
Module
type
M: no module
E: no module, with Ethernet port
G: with 4G module
W: with WIFI module
2-1-3. Model list
Xinje TS5L series HMI has the following models according to different display sizes and function types:
Display size
7〞
10.1〞
General type
TS5L-700
TS5L-700-E
TS5L-700-4G
TS5L-700-W
TS5L-1000
TS5L-1000-E
TS5L-1000-4G
TS5L-1000-W
2-2. Product specification
Product model
TS5L-700
TS5L-1000
Features
Size
7.0”
10.1”
Resolution
800*480
1024*600
LCD
TFT LCD display, LED backlight
Display color
16.77 million colors
Brightness
200 cd/m
2
Touch panel
Four wire resistive touch screen
LCD life
More than 50000 hours, ambient temperature 25℃, 24-hour operation
Processor
Cortex-A8 600MHz
Storage
128MB
Interface
COM1
RS232/RS485
COM2
RS232/RS485/RS422
USB-A port
USB flash disk port, USB2.0
USB-B port
USB download port, USB2.0
