Xinje TS Series User Manual

3
Product model
TS5L-700
TS5L-1000
Ethernet port
Standard RJ45 (10/100M self-adpation)
Audio interface
ɸ3.5 coaxial audio plug
4G (optional)
4G
LTE-FDD (Mbps): 10 (downlink) / 5 (uplink)
WIFI (optional)
IEEE 802.11 a/b/g/n
IEEE 802.11 g: 54Mbps
Electric
features
Input voltage
DC24V (voltage range: DC22V-DC26V)
Current
consumption
200mA
270mA
Allowable
power loss
Below 10ms (the actual power loss is less than 1s)
Voltage impact
resistance
AC1000V, 10mA, less than 1 minute (signal and ground)
Insulation
resistance
Above 10MΩ, DC500V
Environment
Operation
temperature
0-50℃
Storage
temperature
-10-60℃
Operation
humidity
10%RH-90%RH (no condensation)
Anti
interference
capability
Voltage noise: 1500Vp-p, pulse width 1us, 1 minute
Air
No corrosive gas
Cooling
method
Natural air cooling
Protection
Front cover IP65
Dimension
Display area
154.08*85.92 mm
219.6*131.76 mm
Product
dimension
205.8*147.2*35.5 mm
277.0*191.7*37.6 mm
Opening
dimension
192.1*138.5 mm (±0.1)
260.2*179.7 mm (±0.1)
【Note】: Flash rewriting life is 100000 times.
2-3. Part description
2-3-1. Structure description
The following figure shows the reverse area of TS5L HMI. For specific model and appearance, please refer to
the chapter "1-4 Product Dimensions and Installation":

Xinje TS Series Specifications

General

Brand	Xinje
Model	TS Series
Category	Touch Panel
Language	English
