2.3 Interfaces of the Printer

2.3.1 Power interface

2.3.2

Interface of Cash drawer

Cashier-box control: 6-line RJ-11 socket, output DC 24V/1A power signals to drive actions of Cash drawer.

SIGNAL NAME

+24V

GND

N.C

SHELL

F.G

SIGNAL NAME

FGND

Drawer 1

CASH

Drawer 2

GND

654321
