6
FS400 Elliptical
1. Locate the Console Mast (10) and Console Mast Cover (41) and slide
the Cover onto the Mast as far as it will go. Make sure the Console Mast
Cover (41) is facing the correct way.
2. At the top opening of the Main Frame (1) of the elliptical is a Computer
Cable (32). Unravel and straighten out the Computer Cable (32) and
feed it into the bottom of the Console Mast tube (10) and out of the top
opening.
3. Install the Console Mast (10) into the receiving bracket in the top of the
Main Frame (1).Put the four Flat Washers (97) onto the four Hex Head
Bolts (70) and the two Curved Washers (102) onto the two Hex Head
Bolts (70). Tighten by using the 12m/m Wrench (113).
NOTE: There is a electrical wire running through the Console Mast Tube
(10). Be careful not to damage or pinch this Computer Cable (32) during
this procedure.
4. Install the Front Stabilizer(15) on the front stabilizer holding plate at the
bottom of the main frame with the transportation wheels facing forward
and secure them with two Carriage Bolts(148), two Curved Wash-
ers(150) and two Cap Nuts(149) by using 12.14m/m Wrench(111).
FS400 Assembly Instructions
Hardware Step 1
Console Mast & Front Stabilizer
#70. 5/16” x 15mm
Hex Head Bolt (2 pcs)
#97. Ø8 x Ø23 x 1.5T
Flat Washer (4 pcs)
#102. Ø8 x Ø23 x 1.5T
Curved Washer (2 pcs)
#148. 3/8” x UNC16 x
3” Carriage Bolt (2 pcs)
#149. 3/8” x UNC16 x
12.5T Cap Nut (2pcs)
#150. Ø10 x Ø23 x
1.5T Curved Washer
(2pcs)
1
