Make sure that the cable is kept taut in the center of the column pipe and that it is
not sharply bent or pinched.
b) If the discharge column is pressurized, then install a cable entry seal unit in the side
of the column.
1. Cable entry seal unit
2. Support
3. Turnbuckle
4. Cable support grip
Make sure that the impeller rotation is correct. For more information, see .
Clean all debris from the column pipe before starting the pump.
4.8 Install with X-installation
In the X-installation, the pump has no pre-determined mechanical connection. The flange
is drilled.
Figure 13: X-installation
4 Installation
Flygt 3102 Installation, Operation, and Maintenance Manual 25
